07598
Adjustment nuts
-
ADJUSTING NUT D=M10X1 D1=24 STEEL, COMP:CARBON STEELItem No. 07598-024101015
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M10X1
- D=Thread
- M10X1
- D1=Outside diameter
- 24
from £37.38plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M12X1,5 D1=26 STEEL, COMP:CARBON STEELItem No. 07598-026121515
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M12X1,5
- D=Thread
- M12X1,5
- D1=Outside diameter
- 26
from £37.38plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M14X1,5 D1=32 STEEL, COMP:CARBON STEELItem No. 07598-032141516
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M14X1,5
- D=Thread
- M14X1,5
- D1=Outside diameter
- 32
from £38.82plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M16X1,5 D1=34 STEEL, COMP:CARBON STEELItem No. 07598-034161518
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M16X1,5
- D=Thread
- M16X1,5
- D1=Outside diameter
- 34
from £25.56plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M18X1,5 D1=36 STEEL, COMP:CARBON STEELItem No. 07598-036181518
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M18X1,5
- D=Thread
- M18X1,5
- D1=Outside diameter
- 36
from £26.36plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M20X1,5 D1=40 STEEL, COMP:CARBON STEELItem No. 07598-040201518
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M20X1,5
- D=Thread
- M20X1,5
- D1=Outside diameter
- 40
from £26.63plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M22X1,5 D1=40 STEEL, COMP:CARBON STEELItem No. 07598-040221518
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M22X1,5
- D=Thread
- M22X1,5
- D1=Outside diameter
- 40
from £26.75plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M24X1,5 D1=42 STEEL, COMP:CARBON STEELItem No. 07598-042241518
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M24X1,5
- D=Thread
- M24X1,5
- D1=Outside diameter
- 42
from £28.19plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M26X1,5 D1=45 STEEL, COMP:CARBON STEELItem No. 07598-045261520
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M26X1,5
- D=Thread
- M26X1,5
- D1=Outside diameter
- 45
from £28.59plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M28X1,5 D1=46 STEEL, COMP:CARBON STEELItem No. 07598-046281520
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M28X1,5
- D=Thread
- M28X1,5
- D1=Outside diameter
- 46
from £29.25plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M30X1,5 D1=48 STEEL, COMP:CARBON STEELItem No. 07598-048301520
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M30X1,5
- D=Thread
- M30X1,5
- D1=Outside diameter
- 48
from £30.42plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M32X1,5 D1=50 STEEL, COMP:CARBON STEELItem No. 07598-050321522
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M32X1,5
- D=Thread
- M32X1,5
- D1=Outside diameter
- 50
from £31.74plus sales taxplus shipping costsMore details -
ADJUSTING NUT D=M35X1,5 D1=53 STEEL, COMP:CARBON STEELItem No. 07598-053351522
- Product type
- adjustment nut
- Body surface finish
- black oxidised
- G=thread / for thread
- M35X1,5
- D=Thread
- M35x1,5
- D1=Outside diameter
- 53
from £33.06plus sales taxplus shipping costsMore details
Description
Material
Steel.
Clamping screws carbon steel.
Clamping screws carbon steel.
Version
Black oxidised.
Clamping screws ISO 4762, grade 12.9.
Clamping screws ISO 4762, grade 12.9.
Note
Two screw parts that are elastically connected are tightened against each other with screws.
The adjustment nut is constructed rotationally symmetric. There are no unbalancing keyways or slots.
The adjustment nut is constructed rotationally symmetric. There are no unbalancing keyways or slots.
Attention
The adjustment nut can be axially deformed and must be handled with care. The clamping screws may only be tightened when the adjustment nut is completely screwed onto the spindle thread, otherwise the adjustment nut could become defective through unacceptable plastic deformation.
Please log in to download CAD drawings.
Adjusting nuts
Adjustment nuts can be used to e.g. precisely position spindles. A pre-requisite for this is that the adjustment nut remains in position when the spindle rotates. The desired position is fixated by two opposing round nuts. They are joined together elastically and can only be turned using a pin spanner in the holes in the nut face.
