Cam-action indexing plunger are used where any change in locking position due to lateral forces should be prevented. Turning the grip through 180° retracts the indexing pin, enabling a change in the indexed position. The notch ensures that the grip remains in this position and the indexing pin remains retracted.

Threaded sleeve and grip 1.0503.
Indexing pin 1.0718.
Spring 1.4310.

Threaded sleeve and grip black oxidised.
Indexing pin hardened, ground and black oxidised.
Spring bright.

The closed construction of these indexing plungers with internal guide permits them to be installed in places subject to heavy soiling e.g. dust and airborn sparks.

- The indexing pin is retracted by rotating the grip through 180°.
- The closed design prevents dirt from entering the threaded sleeve.
- The hexagon on the sleeve facilitates easy installation of the indexing plunger.

Special versions.

Mounting bracket 03099.
Positioning bushes 03099-50.
