07360

Disc springs DIN EN 16983

  • Suitable for spring packages
  • High spring force with short spring travel
Special features:

from £0.38

plus sales tax
  • 1(current)
  • 2
28 results found
  • 1(current)
  • 2

Description

Material
Spring steel
Version
Phosphated and oiled.
Note
If several disc springs are assembled to form a spring packet i.e. concave face to convex face, the spring force of a single disc can be multiplied by the number of discs giving high spring force with short spring travel.
If several disc springs are assembled to form a spring column i.e. concave face to concave face and convex face to convex face, the spring force of the entire column is the same as that of a single disc giving low spring force with long spring travel.

F = 0.25 x H
