04431-05

Clamping cams

  • Compact design
  • Quick and easy clamping of components
  • Robust construction
Special features:

from £27.18

plus sales tax

Description

Material
Carbon steel.
Version
Black oxidised.
Assembly
1. Screw the locking screw into the collar bush and fixture clamp and screw onto the baseplate.
2. The workpiece is clamped by tightening the fixture clamp with a spanner.
Advantages
- Compact design
- Quick and easy clamping of components
Drawing reference
1) Locking screw
2) Collar bush
3) Fixture clamp
